Digging through catalogs to cross-reference cable dimensions and accessory sizes is a time-consuming process. Our smart configurator handles the heavy lifting for you.
Enter your cable specifications and our configurator will instantly identify the correct Chardon MV connectors and terminations, generating the exact part numbers needed for project specifications or quotation requests.
Configure Your Product
Input your cable specs below to instantly generate the exact Chardon part number for your Purchase Order.
Cable Insulation O.D. Estimator
Quickly estimate your diameter over insulation based on our global market database.
Estimated Diameter over Insulation
0.0 mm
Value copied to the Selector automatically!
⚠️ Note: This is an estimation. Always verify the exact diameter over insulation with your cable manufacturer before installing accessories.
Why do we need both measurements?
The conductor cross-section (e.g., 95 mm²) is standardized and almost always printed on the cable jacket or listed in datasheets. However, cables with the exact same conductor can have vastly different Insulation Outer Diameters depending on their voltage class and the manufacturer's design.
While some catalogs provide the nominal Insulation O.D., manufacturing tolerances mean the real diameter can differ. That is why verifying the exact dimension using an appropriate tool, such as a caliper, is highly recommended before specifying your medium voltage accessory.
1. Sizing the Separable Connector or Termination
The accessory body (adapter or cold shrink) stretches over the insulation. A precise interference fit is critical to eliminate air gaps and control the electric field.
Requires exact Insulation O.D. (mm)
2. Sizing the Metallic Lug
The internal connector (compression or shear-bolt) must perfectly match the core to safely carry the electrical current without overheating.
Requires exact Conductor Size (mm²)
